Downloads
Here you can download our documents, images, videos, software or presentations. Click the tag to filter all resources including the clicked tag. To narrow your search, choose multiple tags. View all files below the wanted group title by clicking the link View all.
Datasheets TWIG Neo Ex
Voir toutDatasheets TWIG Eon
Voir toutFlyers TWIG Neo
Voir toutFlyers TWIG One
Voir toutDatasheets TWIG Neo
Voir toutDatasheets TWIG One
Voir toutDatasheets TWIG One Ex
Voir toutDatasheets TWIG Accessories
Voir toutDatasheets TWIG Easy
Voir toutDatasheets TWIG SOSCard
Voir toutDatasheets TWIG Beacon
Voir tout
TWIG Beacon Scheda tecnica EZ3415-IT
00:10
0
0
TWIG Beacon Datenblatt EZ3415-DE
00:10
0
0
Datasheets TWIG Beacon Ex
Voir toutDatasheets TWIG Tag
Voir toutDatasheets TWIG Remote Button
Voir toutDatasheets TWIG Door Sensor
Voir toutDatasheets TWIG Bracer
Voir toutDatasheets TWIG SRD
Voir toutDatasheets TWIG Point
Voir toutApplication Instructions for Wi-Fi communication
Voir toutDeclarations of Conformity en
Voir tout
Declaration of Conformity RED TUP93EU TWIG SOSCard
Aperçu gratuit
Declaration of Conformity - DoC TWIG SOSCard TUP93EU RED
00:00
0
0
Case Studies
Voir tout
Case Study: TWIG Embody protecting lone workers in indoor emergency situations
Aperçu gratuit
case study
00:00
0
0
Certificates
Voir tout
Quality Certificate ATEX Directive 94/9/EC
Aperçu gratuit
Certificate - Quality Certificate ATEX Directive 94/9/EC
00:00
0
0
Johtamisjärjestelmäsertifikaatti ISO14001:2015
Aperçu gratuit
Certificate - Johtamisjärjestelmäsertifikaatti ISO14001:2015
00:00
0
0
Management System Certificate ISO9001:2015
Aperçu gratuit
Certificate - Quality Certificate ISO9001:2015
00:00
0
0
Johtamisjärjestelmäsertifikaatti ISO9001:2015
Aperçu gratuit
Certificate - Johtamisjärjestelmäsertifikaatti ISO9001:2015
00:00
0
0
Safety Instructions en-de-es-fr-it-nl-no-sv-fi
Voir toutDirectives en
Voir toutRegulations en
Voir tout
00:00
0
0
Terms and policies en
Voir toutPresentations en
Voir toutLeaflets
Voir toutVideos
Voir tout
TWIG Neo marketing video
Aperçu gratuit
The new, small and scalable TWIG Neo provides multiple wearing options making it ideal e.g. for laboratory, maintenance and health care staff.
TWIG Neo adds new features to wearable TWIG devices: 4G data communication, configurable UI and keypad, SRD3 option, robust SIM cradle and Firmware over-the-air.
With SRD3 option TWIG Neo is the first multi-wearable TWIG device to benefit from TWIG Point Netloc hybrid location both for public space location (cellular + Wi-Fi) and for on-site location (TWIG SRD + Wi-Fi + BLE).
TWIG Neo adds new features to wearable TWIG devices: 4G data communication, configurable UI and keypad, SRD3 option, robust SIM cradle and Firmware over-the-air.
With SRD3 option TWIG Neo is the first multi-wearable TWIG device to benefit from TWIG Point Netloc hybrid location both for public space location (cellular + Wi-Fi) and for on-site location (TWIG SRD + Wi-Fi + BLE).
00:00
0
0
How to use man down alarm?
Aperçu gratuit
Man Down alarm system is a sensor based aid to launching emergency cycle that makes automatic call and sends position to predefined numbers in case the user is unable to trigger alarm manually.
Read more about TWIG ManDown alarm on: https://www.twigcom.com/page/mandown-alarm-for-lone-workers
TWIG personal alarm devices support Man Down alarm triggered by 4 independent alert triggers: device orientation, non-movement, free fall and impact.
Alert is launched when predefined parameters are met. In order to minimize false alarms or missing alarms, the Man Down settings need to be carefully matched with the usage scenario and environment. The user needs to be trained on Man Down function and also on understanding its limitations.
Man Down alarm triggered by falling AND no movement
Horizontal + Motion Sensitivity Enabled: TWIG SOS cycle is launched when device main axis orientation deviates from absolute upright position more than Tilt Angle (in degrees), AND detected device movement (acceleration) falls below a threshold value defined by Motion Sensitivity.
Vertical + Motion Sensitivity Enabled : Man Down alert launches TWIG SOS cycle when device beam axis orientation deviates from absolute upright position more than Tilt Angle (in degrees), AND detected device movement (acceleration) falls below a threshold value defined by Motion Sensitivity.
Man Down alert is triggered when both rules are met:
- device main or beam axis orientation deviates from absolute upright position and
- device movement falls below a threshold value defined by motion sensitivity.
Man Down+ alarm triggered by falling OR no movement
TWIG personal alarms supporting Man Down+ feature alerts the ARC also in situations where the user is not moving (e.g. because of unconsciousness) but the personal alarm is not deviating enough from the absolute tilt angle (e.g. where fainting doesn’t include falling and change in device orientation axis). In situation of no movement SOS cycle is launched when detected device movement (acceleration) falls below a threshold value defined by Motion Sensitivity. Device orientation has no effect.
Man Down++ alarm triggered by free fall or impact
The TWIG personal alarms supporting Man Down++ feature alerts the ARC also in situations of a sudden impact or free falling.
Read more about TWIG ManDown alarm on: https://www.twigcom.com/page/mandown-alarm-for-lone-workers
TWIG personal alarm devices support Man Down alarm triggered by 4 independent alert triggers: device orientation, non-movement, free fall and impact.
Alert is launched when predefined parameters are met. In order to minimize false alarms or missing alarms, the Man Down settings need to be carefully matched with the usage scenario and environment. The user needs to be trained on Man Down function and also on understanding its limitations.
Man Down alarm triggered by falling AND no movement
Horizontal + Motion Sensitivity Enabled: TWIG SOS cycle is launched when device main axis orientation deviates from absolute upright position more than Tilt Angle (in degrees), AND detected device movement (acceleration) falls below a threshold value defined by Motion Sensitivity.
Vertical + Motion Sensitivity Enabled : Man Down alert launches TWIG SOS cycle when device beam axis orientation deviates from absolute upright position more than Tilt Angle (in degrees), AND detected device movement (acceleration) falls below a threshold value defined by Motion Sensitivity.
Man Down alert is triggered when both rules are met:
- device main or beam axis orientation deviates from absolute upright position and
- device movement falls below a threshold value defined by motion sensitivity.
Man Down+ alarm triggered by falling OR no movement
TWIG personal alarms supporting Man Down+ feature alerts the ARC also in situations where the user is not moving (e.g. because of unconsciousness) but the personal alarm is not deviating enough from the absolute tilt angle (e.g. where fainting doesn’t include falling and change in device orientation axis). In situation of no movement SOS cycle is launched when detected device movement (acceleration) falls below a threshold value defined by Motion Sensitivity. Device orientation has no effect.
Man Down++ alarm triggered by free fall or impact
The TWIG personal alarms supporting Man Down++ feature alerts the ARC also in situations of a sudden impact or free falling.
00:00
0
0
TWIG One and TWIG One Ex personal alarm devices
Aperçu gratuit
Copy link for download:
ftp://ftp.twigcom.com/PublicDocuments/Videos/TWIG_One_and_TWIG_One_Ex_Animation_with_text.mp4
ftp://ftp.twigcom.com/PublicDocuments/Videos/TWIG_One_and_TWIG_One_Ex_Animation_with_text.mp4
00:00
0
0
TWIG Point service provider platform for TWIG personal alarms
Aperçu gratuit
TWIG Point SP is a modular suite of cloud services to manage and monitor TWIG personal alarm devices. Deployed internationally in minutes, the TWIG Point SP combines ease of use and remote device management with powerful features such as location fusion, custom floor plans and API.
00:00
0
0
